Landforms in the upper course of a river
The diagram below shows the typical characteristics of the upper course of a river valley.
Typical features of the upper course of a river:
Interlocking spurs are fingers of land that jut out into the river valley where streams and rivers are forced to flow around in the upper course.
The characteristics of interlocking spurs are:
V-shaped valleys and interlocking spurs are commonly found in a river’s upper course.
As small streams and rivers tumble down mountainsides, they are forced to flow around ‘fingers’ of land that jut out into the river valley. It is these ‘fingers’ of land that are the interlocking spurs.
Vertical rather than lateral erosion dominates in the upper course of the river. This deepens the valley by hydraulic action and abrasion but does not erode sideways into the interlocking spurs.
Low energy means the water isn’t strong enough to erode resistant rocks in the spur, so it follows the path of least resistance. This explains why the river is forced to flow around them.
This erosion and the movement of weathered material at the sides of the river create the classic V-shaped valley.
Rapids are fast-flowing, turbulent sections of the river where the bed has a relatively steep gradient. They are found in the upper course of the river.
Rapids form when there is vertical bedding and alternate bands of hard and soft rock cross the channel. Differential erosion will occur as the soft rock is more easily eroded than hard rock. This makes the riverbed uneven, and a river’s flow becomes turbulent, leading to white water sections typical of rapids.
Waterfalls commonly form when water rushes down steep hillsides in upland areas. They are typical of the upper valley but can be found in the river’s lower courses. The height and number of waterfalls along a stream or river depend upon the type of rocks that are being eroded by the water. This typically occurs in areas where alternating rock bands, made up of soft and hard rock, form the bedrock. Some types of rocks (shale, for example) wear away more quickly than others (such as sandstone or limestone).
Waterfalls form when water falls onto soft rock after flowing over hard rock. Falling water and rock particles erode the soft rock below, forming a plunge pool. Erosion processes, such as hydraulic action, abrasion and corraision further erode the plunge pool and the back wall of the waterfall, undercutting the hard rock above. Eventually, the hard rock will no longer be supported and collapse. The waterfall continues to retreat, leaving behind a steep-sided gorge.
The diagram below shows the formation of a waterfall.
The video below shows an overhang beneath Summerhill Force waterfall, Bowlees, Teesdale.
Another example of a waterfall is High Force on the River Tees. At 22 metres, it is the tallest waterfall in England. The River Tees tumbles over the Whin Sill, a layer of a hard rock called dolerite, which is known locally as whinstone. This resistant rock lies on top of softer sandstone, shale and limestone. The retreating waterfall has created a gorge 500m long.
Below is a video featuring Skógafoss, a waterfall situated on the Skógá River in the south of Iceland at the cliffs of the former coastline.
A gorge can be formed as a waterfall retreats up a valley. This happens when a river flows over a band of hard rock that lies over the top of the softer, less resistant rock. The river erodes the softer rock faster, through hydraulic action and abrasion. This erosion leads to the undercutting of the softer rock. Over time an overhang of hard rock forms. Eventually, the overhang collapses as it cannot support itself. This process repeats causing the waterfall to retreat upstream, leaving behind a steep and narrow gorge.
